Features:
1. Small volume, waterproof, anti vibration, no noise, no contact arc;
2. Built in resistance capacitance absorption circuitt, long service life, strong anti-interference, high reliability;
3. Basic TRIAC phase-shifting regulation output, enhanced SCR phase-shifting regulation output;
4. It can be matched with the output signal interface of temperature control instrument and microcomputer;
5. Multi function signal input can be selected, the phase-shift is from 180 to 0 degrees, standardized size;
6. .

Applications:
The module has photoelectric isolation to realize the control of weak current to strong current and the control of output power by input voltage, high input resistance, internal synchronization, can be directly through the digital to analog converter and computer, digital circuit and with 0-5V, 0-10V voltage or 4-20mA current output instrument interface, realize the stepless adjustment of output power.
It can be used in lighting adjustment, temperature control of heating equipment, speed regulation of AC motor, electromagnet vibration, power adjustment of transformer, etc.

Code£ºZ02U
